Network Taps Ntap

Descripción

Description
Transfers gigabit traffic from a full-duplex optical link to a copper monitoring device
Compatible with network analyzers, security monitoring devices, forensics tools, remote monitoring appliances, and RMON probes
Overview

Install Aggregator nTAPs on 10 Mb, 100 Mb, or 1 Gb links for quick, anytime access to network traffic. Designed for low-to-moderate utilization full-duplex links, Aggregator nTAPs merge data into single streams for transmission up to two single-receive analysis devices. Industry-leading buffer sizes offer less likelihood of lost packets than SPAN ports to ensure critical traffic reaches analyzers, remote monitoring appliances, and forensics tools. For networks and analyzers of different topologies, a Conversion Aggregator nTAP is available.

Technical Specifications

Optical Specs

Maximum Insertion Losses (dB)

Split Ratio Multimode 62.5 µm Multimode 50 µm Single-mode 9 µm
(1300 nm) (850 nm) (1300 nm) (850 nm) (1310/1550 nm)
50/50 3.9/3.9 dB 4.7/4.7 dB 4.5/4.5 dB 5.5/5.5 dB 3.6/3.6 dB
60/40 3.0/5.0 3.8/5.7 3.7/5.6 4.7/6.6 2.8/4.8
70/30 2.3/6.3 3.0/7.0 2.9/7.0 3.9/8.0 2.0/6.1
80/20 1.7/8.3 2.4/9.0 2.3/9.0 3.2/10.0 1.3/8.0
90/10 1.2/12 1.9/12.5 1.8/12.8 2.7/13.5 .8/12.0
Supported Media

Fiber type Multimode Single-mode
Connector LC LC
Fiber Diameter(s) 50 µm or 62.5 µm 9 µm
Wavelength Ranges (dual window) 850 nm or 1300 nm 1310 nm or 1550 nm
Environmental Requirements

Specification Operational Range
Temperature Range (operating) -40° to 185° (F) / -40° to 85° (C)
Temperature Range (storage) -52° to 185° (F) / -47° to 85° (C)
Copper Specs

Supported Media

Interface Media
Link A/Link B (Link under test) RJ45
Copper Analyzer Interface RJ45
