Tarjeta Madre Gigabyte Ga A55m-ds2 Socket Fm1 New! Ultimas

Descripción

ATENCION LEA ATENTAMENTE

ANTES DE OFERTAR DIRECTAMENTE CONSULTE EXISTENCIAS Y CARACTERISTICAS DE
COMPATIBILIDAD CON SU PROCESADOR Y TARJETA DE VIDEO SI LA HUBIERE
CUALQUIER OFERTA SIN ANTES CONSULTAR SERÁ RECHAZADA Y EL DINERO DEVUELTO Y DESCONTADAS LAS COMISIONES QUE SE HUBIEREN GENERADO , GRACIAS


Atención Últimas piezas en socket FM1 hasta agotar existencias.

TENEMOS STOCK PROPIO , ENTREGA INMEDIATA

APU
FM1 Socket:
AMD A series & E2 series processors
(Please refer "CPU Support List" for more information.)
Chipset
AMD A55 chipset
Memoria
2 x 1.5V DDR3 DIMM sockets supporting up to 64 GB of system memory (Note 1)
* The maximum 64 GB of system memory can be supported using 16 GB (or above) memory modules. GIGABYTE will update the memory support list on the official website when the memory modules are available on the market.
Dual channel memory architecture
Support for DDR3 1866/1600/1333/1066 MHz memory modules
(Please refer "Memory Support List" for more information.)
Gráficos Integrados
APU:
1 x D-Sub port (Note 2)
1 x DVI-D port, supporting a maximum resolution of 1920x1200 (Note 2) (Note 3)
(All integrated graphics ports do not support Hot plug. If you want to change to another graphics port when the computer is on, be sure to turn off the computer first.)
Audio
VIA HD audio codec
High Definition Audio
2/4/5.1/7.1-channel (Note 4)
Support for S/PDIF Out
LAN
1 x Atheros GbE LAN chip (10/100/1000 Mbit)
Puertos de Expansión
1 x PCI Express x16 slot, running at x16
1 x PCI Express x1 slot
(All PCI Express slots conform to the PCI Express 2.0 standard.)
1 x PCI slot
Interfaz de Almacenamiento
Chipset:
4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices
Support for RAID 0, RAID 1, RAID 10, and JBOD
Tecnología Multi-Gráficos
Support for AMD Dual Graphics technology
Only A series APU support AMD Dual Graphics.
USB
Chipset:
Up to 8 USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
Conectores Internos de E/S
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
4 x SATA 3Gb/s connectors
1 x APU fan header
1 x system fan header
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
2 x USB 2.0/1.1 headers
1 x serial port header
1 x clearing CMOS jumper
Conectores del Panel Trasero
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x D-Sub port
1 x DVI-D port
4 x USB 2.0/1.1 ports
1 x RJ-45 port
3 x audio jacks (Line In/Line Out/Microphone)
Controlador de E/S
iTE IT8728 chip
Monitorización H/W
System voltage detection
APU/System temperature detection
APU/System fan speed detection
APU overheating warning
APU/System fan fail warning
APU/System fan speed control (Note 5)
BIOS
2 x 32 Mbit flash
Use of licensed AWARD BIOS
Support for DualBIOS™
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Características Únicas
Support for @BIOS
Support for Q-Flash
Support for Xpress BIOS Rescue
Support for Download Center
Support for Xpress Install
Support for Xpress Recovery2
Support for EasyTune (Note 6)
Support for Smart Recovery
Support for Auto Green
Support for ON/OFF Charge
Support for 3TB+ Unlock
Support for Q-Share

Software Incluido
Norton Internet Security (OEM version)
Sistema Operativo
Support for Microsoft® Windows 8/7/Vista/XP
Diseño
Micro ATX Form Factor; 22.5cm x 17.4cm
Nota
(Note 1) Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than 4 GB.

(Note 2) To use the onboard D-Sub, DVI, Display port or HDMI, must install an AMD CPU with integrated graphics.

(Note 3) The DVI-D port does not support D-Sub connection by adapter.

(Note 4) To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.

(Note 5) Whether the APU/system fan speed control function is supported will depend on the APU/system cooler you install.

(Note 6) Available functions in EasyTune may differ by motherboard model.
